First configure under DMR Configuration, select DMRGateway and apply, after the services restart and page refreshes, you’ll see several additional options under DMR Configuration.
Select the BrandMeister Master you want to use and configure your BM Hotspot security if it’s enabled in your BM Selfcare.
Also be sure to select the correct ESSID for BM that you wish to use.
Lastly toggle BrandMeister Network to be enabled, and click Apply Changes.
Next to add TGIF, go to Configuration -> Expert Editor, and select the Full Edit DMR GW. Scroll to the end and add the [DMR Network 4] config, be sure to supply your DMR ID for the Id:
[DMR Network 4]
Enabled=1
Name=TGIF_Network
PCRewrite1=1,4009990,1,9990,1
PCRewrite2=2,4009990,2,9990,1
TypeRewrite1=1,4009990,1,9990
TypeRewrite2=2,4009990,2,9990
TGRewrite1=1,4000001,1,1,999999
TGRewrite2=2,4000001,2,1,999999
SrcRewrite1=1,9990,1,4009990,1
SrcRewrite2=2,9990,2,4009990,1
SrcRewrite3=1,1,1,4000001,999999
SrcRewrite4=2,1,2,4000001,999999
Address=tgif.network
Password=passw0rd
Port=62031
Location=0
Debug=0
Id= –THIS SHOULD BE YOUR DMR ID–
Click Apply Changes, and then Reboot the hotspot.
To access BrandMeister Talkgroups, use the actual talkgroup number on your radio, so TG 91 on BM should be programmed as TG 91 on your Radio.
To access TGIF Talkgroups, you need to prefix the TGIF talkgroup number with 4 plus any additional zeros so the TG number is 7 digits long. Example is TGIF TG 777 should be programmed as TG 4000777 on your radio and TGIF TG 31665 would be programmed as `TG 4031665`. TGIF disconnect should be programmed as TG 4004000.
